Supermax SuperBrush Single 49"

Price
$ 19,999

Have questions? Give us a call at 260-637-0054.

These easy to use machines come with an extremely low learning curve and offer many different features which include: quick change brush heads, infinitely variable brush and conveyor speeds to allow for endless finish possibilities, adjustable tension rollers to prevent stock slippage, and precision height adjustments. Our SuperBrush™ sanders come in sizes ranging from 24″ to 49″ with single and/or double brush head offerings to meet all your finishing needs.

The SuperBrush has these great benefits over hand finishing:

  • Faster Output
  • Reduce Rework
  • Greater Surface Consistency

Here are just a few applications for a Single Brush:

  • Raw Wood Sanding
  • White Wood Sanding
  • Break sharp edges
  • Blend out minor defects
  • Sealer Sanding
  • Primer Sanding
  • Scuff Sanding
  • Profile sanding
  • Clean reclaimed wood
  • Wire brushing to pull out soft grain to create a textured surface

All Laguna Tools woodworking machinery carry a 2-year warranty. Must register machine within 30 days of purchase.

Features
  • Infinitely variable brush speed and conveyor feed rate allows for a wide variety of finishes
  • Quickly change brush heads or abrasive loadings
  • Fully adjustable tension rollers prevent stock slippage
  • Reinforced steel conveyor bed with a poly conveyor belt
  • Precision height adjustment
  • Bristle Contact Gauge included
Specs

Sanding Capacity
Maximum Width:
49"
Minimum Length: 10"
Maximum Thickness: 11″, varies with brush style
Minimum Thickness: 1/32″
Dimensions (H x W x D):  50" x 71" x 31"
Brush: 9″ – 11″ Typical Diameter
Typical Bristle Length: 1-1/2" – 3″
Speed: Ranged variable, 400-1200 RPM brush
Dust Hood: Steel With Hinged Back; Three, 4″ Vacuum Port; 1800 CFM Minimum
Drive Motor (TEFC): 7-1/2 HP
Power Requirements: 220V 7.5 HP 3ph 40 amp service *Note: A power cord and plug are not included and need to be sourced locally and installed.
Shipping Weight: 775 lbs.
Conveyor Motor: Direct Drive D.C. Motor, infinitely variable, 0-15 FPM; 200 in.-lb. torque

SKU: SUPMX-93497
